Hydraulic Hoses SAE 100 R1/1 SN

APPLICATION
Medium Pressure Hydraulic Lines 35 to 250 bar and requires compact outer dia. for use with Petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Agricultural, earthmoving & Material handling equipments and machineries/systems.

APPLICABLE STANDARD
Standard: SAE J517 – 100R2 /EN853 – 2SN
CONSTRUCTION
Core: oil & water resistant synthetic rubber
Reinforcement: Double steel wire braids
Cover: Black color, synthetic rubber resistant to
weather and abrasion, oil & ozone
TEMPERATURE RANGE
Continuous: -40c to + 100c
Impulse cycles: 200,000 ;
Tested upto 400,000 cycles, upto 1″I.D

Dash DN Hose I.D.
(Nom.)		 Hose O.D.
(Nom.)		 Working Pressure Min. Burst Pressure Min. Bend Radius
-3 5
-4 6
-5 8
-6 10
-8 12
-10 16
-12 20
-16 25
-20 32
-24 38
-32 50
-40 63
-48 75
(In) (mm)
3/16 4.8
1/4 6.4
5/16 8.0
3/8 9.5
1/2 12.7
5/8 16.0
3/4 19
1 25.4
1.1/4 31.8
1.1/2 38.1
2 50.8
2.1/2 63.5
3 76.2
(In) (mm)
0.47 12.0
0.52 13.2
0.59 15.1
0.68 17.2
0.79 20.2
0.93 23.6
1.08 27.5
1.39 35.3
1.70 43.2
1.95 49.6
2.50 63.5
3.11 79.0
3.62 92.0
(psi) (Bar)
3625 250
3275 225
3125 215
2625 180
2325 160
1900 130
1525 105
1275 88
915 63
725 50
580 40
525 36
508 35
(psi) (Bar)
14500 1000
13100 900
12500 860
10500 720
9300 640
7600 520
6100 420
5100 352
3660 252
2900 200
2320 160
2900 200
2030 140
(mm) (In)
90 3.60
100 4.00
105 4.20
130 5.20
180 7.20
200 8.00
240 9.50
300 12.00
420 16.60
500 19.70
630 25.25
760 30.40
900 36.00
